FU Series

High Temperature Resistant Fiber Optic Cable


  • Product advantages
  • Parameter specifications
  • Product size
  • Wiring diagram
Product Features

High protection and strong toughness stainless steel wire body

The high toughness stainless steel shell material has strong properties such as high tensile strength, corrosion resistance, oil stain resistance, and impact resistance, making it more durable without fear of wear.


High temperature resistance 350 ℃

can be used in high temperature environments ranging from 100 to 350 ℃, suitable for various high-temperature environments such as the kiln industry, high-temperature ovens, tunnel furnaces, etc.

The inner core of high permeability optical fiber

consists of an optical fiber core and a stainless steel cladding, which can effectively protect the optical fiber core, making it more durable and anti-interference. At the same time, it has high strength toughness and bending performance, making it less prone to fracture and power outage. Stable signal transmission with low loss.




 diffuse reflection
 appearance  model  size  sense distance Reliable sensing distance operation temperature  bending radius Minimum detectable substance  Fiber Material  Fiber optic tube material
 FU-RSG310  M3*22.7  90mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-RSG410  M4*25.7  90mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-RSG610  M6*25  90mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-RSG310-TZ  M3*14.5  90mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass stainless steel
 FU-RSG410-TZ  M4*16.2  90mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-RSG610-TZ  M6*17.2  400mm±10%  0-72mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel

 correlation
 appearance  model  size  sense distance Reliable sensing distance  operation temperature bending radius Minimum detectable substance Fiber Material  Fiber optic tube material
 FU-TG310  M3*22.7  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-TG410  M4*25.7  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-TG610  M6*25  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass   stainless steel
 FU-TG310-TZ  M3*14.5  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-TG410-TZ  M4*16.2  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
 FU-TG610-TZ  M6*17.2  3000mm±10%  0-2800mm  -55~+350℃  R25mm  φ0.1mm  glass  stainless steel
